immediate downloadReleased: 1995-05-15
BS G 253:1995
Specification for type 1 terminal junction systems
Format
Availability
Price and currency
English Secure PDF
Immediate download
249.60 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
24.96 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
74.88 EUR
English Hardcopy
In stock
249.60 EUR
| Standard number: | BS G 253:1995 |
| Pages: | 24 |
| Released: | 1995-05-15 |
| ISBN: | 0 580 24045 2 |
| Status: | Standard |
DESCRIPTION
BS G 253:1995
This standard BS G 253:1995 Specification for type 1 terminal junction systems is classified in these ICS categories:
- 49.060 Aerospace electric equipment and systems
1.1 This part of ISO 8668 specifies the particular characteristics of a terminal junction system (TJS), designated as type 1 and intended for use at temperatures between − 55 °C and + 155 °C.
1.2 The junction systems covered by this part of ISO 8668 comprise:
- feedback modules in four sizes;
- feedthrough modules in four sizes;
- frames adapted to these modules: standard frame P1, perforated frame P2 or frame P3 for feedback modules; solid frame P4 for feedthrough modules;
- module clamps and inserts;
- removable identification tags;
- removable male crimp contacts of sizes 22, 20, 16 and 12;
- sealing plugs.
