BS G 254:1994 Specification for type 2 terminal junction systems

BS G 254:1994

Specification for type 2 terminal junction systems

Format
Availability
Price and currency
English Secure PDF
Immediate download
266.20 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
26.62 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
79.86 EUR
English Hardcopy
In stock
266.20 EUR
Standard number:BS G 254:1994
Pages:30
Released:1994-03-15
ISBN:0 580 22866 5
Status:Standard
DESCRIPTION

BS G 254:1994


This standard BS G 254:1994 Specification for type 2 terminal junction systems is classified in these ICS categories:
  • 49.060 Aerospace electric equipment and systems

1.1 This part of ISO 8668 specifies the particular characteristics of a terminal junction system (TJS), designated as type 2, and intended for use at temperatures from − 55 °C to + 155 °C.

1.2 The junction system covered by this part of ISO 8668 comprises:

  1. feedback modules in four sizes;
  2. feedthrough modules in four sizes;
  3. frames adapted to these modules: monolithic frame and double frame for feedback modules, and double frame for feedthrough modules;
  4. spacers;
  5. removable male crimp contacts of sizes 22, 20, 16 and 12;
  6. sealing plugs.
