immediate downloadReleased: 2018-10-26
BS ISO 10110-14:2018
Optics and photonics. Preparation of drawings for optical elements and systems Wavefront deformation tolerance
Format
Availability
Price and currency
English Secure PDF
Immediate download
191.18 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
19.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
57.35 EUR
English Hardcopy
In stock
191.18 EUR
| Standard number: | BS ISO 10110-14:2018 |
| Pages: | 22 |
| Released: | 2018-10-26 |
| ISBN: | 978 0 580 92248 0 |
| Status: | Standard |
DESCRIPTION
BS ISO 10110-14:2018
This standard BS ISO 10110-14:2018 Optics and photonics. Preparation of drawings for optical elements and systems is classified in these ICS categories:
- 37.020 Optical equipment
- 01.100.20 Mechanical engineering drawings
This document specifies rules for the indication of the permissible deformation of a wavefront transmitted through or, in the case of reflective optics, reflected from an optical element or assembly in the ISO 10110 series, which standardizes drawing indications for optical elements and systems.
This document is also applicable when using optical systems with general surfaces (ISO 10110‑19).
The deformation of the wavefront refers to its departure from the desired shape. The tilt of the wavefront with respect to a given reference surface is excluded from this document.
There is no requirement that a tolerance for wavefront deformation is indicated.
