immediate downloadReleased: 2013-04-30
BS ISO 14540:2013 Hydraulic fluid power. Dimensions and requirements for screw-to-connect quick-action couplings for use at a pressure of 72 MPa (720 bar)

BS ISO 14540:2013

Hydraulic fluid power. Dimensions and requirements for screw-to-connect quick-action couplings for use at a pressure of 72 MPa (720 bar)

Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
Standard number:BS ISO 14540:2013
Pages:18
Released:2013-04-30
ISBN:978 0 580 73940 8
Status:Standard
DESCRIPTION

BS ISO 14540:2013


This standard BS ISO 14540:2013 Hydraulic fluid power. Dimensions and requirements for screw-to-connect quick-action couplings for use at a pressure of 72 MPa (720 bar) is classified in these ICS categories:
  • 23.100.40 Piping and couplings

This International Standard specifies dimensional and performance requirements for hydraulic screw-to-connect quick-action couplings designed to be used at pressure of 72 MPa (720 bar1) in static conditions as an interface between a hydraulic power unit and a tool. Typical applications for these couplings are related to hydraulic jacks, rams, clamping devices, hand tools, and cylinders.

This International Standard covers two types of such couplings: the “P” type, which has a poppet valve, and the “S” type, which has a spherical valve.

1 1 bar = 100 kPa = 105 Pa = 0,1 MPa; 1 Pa = 1 N/m2
