immediate downloadReleased: 2017-08-09
BS ISO 20401:2017 Pneumatic fluid power systems. Directional control valves. Specification of pin assignment for 8 mm and 12 mm diameter electrical round connectors

BS ISO 20401:2017

Pneumatic fluid power systems. Directional control valves. Specification of pin assignment for 8 mm and 12 mm diameter electrical round connectors

Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
Standard number:BS ISO 20401:2017
Pages:16
Released:2017-08-09
ISBN:978 0 580 91688 5
Status:Standard
DESCRIPTION

BS ISO 20401:2017


This standard BS ISO 20401:2017 Pneumatic fluid power systems. Directional control valves. Specification of pin assignment for 8 mm and 12 mm diameter electrical round connectors is classified in these ICS categories:
  • 23.100.50 Control components

This document specifies the pin assignment for pneumatic directional control valves when used together with 8 mm and 12 mm diameter electrical round connectors according to IEC 60947‑5‑2 . This definition is valid for connectors as shown in IEC 60947‑5‑2:2004, Figures D.2 and D.4, which are shown in Clause 4.
