BS ISO 3601-2:2016
Fluid power systems. O-rings Housing dimensions for general applications
| Standard number: | BS ISO 3601-2:2016 |
| Pages: | 66 |
| Released: | 2017-07-31 |
| ISBN: | 978 0 580 51090 8 |
| Status: | Standard |
BS ISO 3601-2:2016
This standard BS ISO 3601-2:2016 Fluid power systems. O-rings is classified in these ICS categories:
- 23.100.60 Filters, seals and contamination of fluids
- 83.140.50 Seals
This part of ISO 3601 specifies the housing (gland) dimensions for class A O-rings for general industrial applications conforming to ISO 3601‑1 , as well as housing dimensions for class B O-rings used on selected metric-dimensioned hardware, e.g. fluid power cylinder bores and piston rods. These O-rings are for use in general hydraulic and pneumatic applications without and with anti-extrusion rings (back-up rings). The dimensions of the O-rings ( d 1 and d 2), size codes (SC) and tolerances conform to ISO 3601‑1 .
Housing dimensions for the O-rings intended for aerospace applications that are specified in ISO 3601‑1 are addressed in Annex A.
It is expected that O-ring housing dimensions for special applications be agreed upon between the O-ring manufacturer and the user.
The terms “housing”, “groove” and “gland” are interchangeable, and their usage is a matter of local convenience. In this part of ISO 3601 , the term “housing” is used exclusively.
