immediate downloadReleased: 2008-07-31
BS ISO 3601-4:2008
Fluid power systems. O-rings Anti-extrusion rings (back-up rings)
Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
| Standard number: | BS ISO 3601-4:2008 |
| Pages: | 22 |
| Released: | 2008-07-31 |
| ISBN: | 978 0 580 56330 0 |
| Status: | Standard |
DESCRIPTION
BS ISO 3601-4:2008
This standard BS ISO 3601-4:2008 Fluid power systems. O-rings is classified in these ICS categories:
- 83.140.50 Seals
- 23.100.60 Filters, seals and contamination of fluids
This part of ISO 3601 specifies dimensions and tolerances for five types of anti-extrusion rings, which are also known as back-up rings:
spiral type (T1);
angle cut type (T2);
solid type (T3);
angle cut concave type (T4);
solid concave type (T5).
These anti-extrusion rings are for use with selected O-ring sizes as specified in ISO 3601-1 and the relevant housing dimensions specified in ISO 3601-2.
