immediate downloadReleased: 2011-10-31
BS ISO 4397:2011 Fluid power connectors and associated components. Nominal outside diameters of tubes and nominal hose sizes

BS ISO 4397:2011

Fluid power connectors and associated components. Nominal outside diameters of tubes and nominal hose sizes

Format
Availability
Price and currency
English Secure PDF
Immediate download
151.20 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
15.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
45.36 EUR
English Hardcopy
In stock
151.20 EUR
Standard number:BS ISO 4397:2011
Pages:14
Released:2011-10-31
ISBN:978 0 580 66846 3
Status:Standard
DESCRIPTION

BS ISO 4397:2011


This standard BS ISO 4397:2011 Fluid power connectors and associated components. Nominal outside diameters of tubes and nominal hose sizes is classified in these ICS categories:
  • 23.100.40 Piping and couplings

This International Standard specifies information on the nominal outside diameters of rigid or semi-rigid tubing and nominal hose sizes to be used with hydraulic and pneumatic fluid power connectors and associated components:

  1. nominal outside diameters for rigid or semi-rigid tubes, irrespective of material composition, used in fluid power;

  2. a list of nominal sizes for hoses made of rubber or plastic used in fluid power.

NOTE Actual outside diameters and tolerances for steel tubes can be found in ISO 3304 and ISO 3305; actual dimensions and tolerances for hose inside diameters can be found in ISO 1307.
