immediate downloadReleased: 2012-01-31
BS ISO 5291:2011
Belt drives. Grooved pulleys for joined classical V-belts. Groove sections AJ, BJ, CJ and DJ (effective system)
Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
| Standard number: | BS ISO 5291:2011 |
| Pages: | 16 |
| Released: | 2012-01-31 |
| ISBN: | 978 0 580 70601 1 |
| Status: | Standard |
DESCRIPTION
BS ISO 5291:2011
This standard BS ISO 5291:2011 Belt drives. Grooved pulleys for joined classical V-belts. Groove sections AJ, BJ, CJ and DJ (effective system) is classified in these ICS categories:
- 21.220.10 Belt drives and their components
This International Standard specifies the principal characteristics of grooved pulleys (for groove sections AJ, BJ, CJ and DJ), intended to take joined classical V-belts for industrial power transmission drives.
NOTE 1 The effective width of a groove is regarded as the basic dimension of standardization for grooves and for the corresponding joined V-belts considered as a whole.
NOTE 2 The pitch line position can only be given approximately. The approximate pitch diameter of a pulley can be calculated by the following formula:
dp = de − 2be
