BS ISO 6164:2018 Hydraulic fluid power. Four-screw, one-piece square flange connections for use at pressures of 42 MPa, DN 25 to 80

BS ISO 6164:2018

Hydraulic fluid power. Four-screw, one-piece square flange connections for use at pressures of 42 MPa, DN 25 to 80

Format
Availability
Price and currency
English Secure PDF
Immediate download
249.60 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
24.96 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
74.88 EUR
English Hardcopy
In stock
249.60 EUR
Standard number:BS ISO 6164:2018
Pages:24
Released:2018-06-01
ISBN:978 0 580 91227 6
Status:Standard
DESCRIPTION

BS ISO 6164:2018


This standard BS ISO 6164:2018 Hydraulic fluid power. Four-screw, one-piece square flange connections for use at pressures of 42 MPa, DN 25 to 80 is classified in these ICS categories:
  • 23.100.40 Piping and couplings

This document gives general and dimensional specifications for flanged heads, flange clamps, ports and mounting surfaces applicable to four-screw, one-piece square flange clamp type tube connectors and hose fittings for use at a pressure of 42 MPa [420 bar1]. It also specifies the dimensions of the seals to be used, as well as the grooves that house the seals.

These connections are intended for application in hydraulic systems on industrial and commercial products where it is desired to avoid the use of threaded connectors.

1 1 bar = 0,1 MPa = 105 Pa; 1 Pa = 1 N/m2.
