immediate downloadReleased: 2014-10-31
BS ISO 6358-3:2014
Pneumatic fluid power. Determination of flow-rate characteristics of components using compressible fluids Method for calculating steady-state flow-rate characteristics of systems
Format
Availability
Price and currency
English Secure PDF
Immediate download
348.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
34.80 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
104.40 EUR
English Hardcopy
In stock
348.00 EUR
| Standard number: | BS ISO 6358-3:2014 |
| Pages: | 70 |
| Released: | 2014-10-31 |
| ISBN: | 978 0 580 61666 2 |
| Status: | Standard |
DESCRIPTION
BS ISO 6358-3:2014
This standard BS ISO 6358-3:2014 Pneumatic fluid power. Determination of flow-rate characteristics of components using compressible fluids is classified in these ICS categories:
- 23.100.01 Fluid power systems in general
This part of ISO 6358 specifies a method that uses a simple numerical technique to estimate without measurements the overall flow-rate characteristics of a system of components and piping with known flow-rate characteristics.
The formulae used in this part of ISO 6358 describe the behaviour of a compressible fluid flow through a component for both subsonic and choked flows.
NOTE The conductance of a tube, silencer or filter is influenced by the upstream pressure, so the values of C and b are only valid for the upstream pressure at which they are determined.
This part of ISO 6358 also provides methods to obtain equivalent flow-rate characteristics for components whose flow-rate characteristics differ from those defined in the ISO 6358 series.
