BS ISO 8434-6:2009 Metallic tube connections for fluid power and general use 60° cone connectors with or without O-ring

BS ISO 8434-6:2009

Metallic tube connections for fluid power and general use 60° cone connectors with or without O-ring

Format
Availability
Price and currency
English Secure PDF
Immediate download
348.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
34.80 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
104.40 EUR
English Hardcopy
In stock
348.00 EUR
Standard number:BS ISO 8434-6:2009
Pages:52
Released:2010-09-30
ISBN:978 0 580 71800 7
Status:Standard
DESCRIPTION

BS ISO 8434-6:2009


This standard BS ISO 8434-6:2009 Metallic tube connections for fluid power and general use is classified in these ICS categories:
  • 23.100.40 Piping and couplings

This part of ISO 8434 specifies general and dimensional requirements for the design and performance of 60° cone connectors and braze-on nipples with or without O-ring sealing, made of steel for tube outside diameters of 6 mm through 50 mm, inclusive, or hose sizes 5 through 51, inclusive. These connectors are for use in fluid power and general applications within the limits of pressure and temperature specified in this part of ISO 8434.

They are intended for the connection of tubes and hose fittings to ports in accordance with ISO 6149-1 and ISO 1179-1. See ISO 12151-6 for related hose fitting specification.

These connectors provide full-flow connections in hydraulic systems operating to the working pressures shown in Table 1.

NOTE 1 For new designs in hydraulic fluid power applications, see the requirements given in 9.6. Where the requirements of the application allow for the use of elastomeric seals, connector designs that conform to International Standards and incorporate elastomeric sealing are preferred.

NOTE 2 For use under conditions outside the pressure and/or temperature limits specified, see 5.3.
