Homepage>BS Standards>49 AIRCRAFT AND SPACE VEHICLE ENGINEERING>49.030 Fasteners for aerospace construction>49.030.30 Nuts>BS ISO 9618:2016 Aerospace. Nuts, hexagonal, slotted (castellated), reduced height, normal across flats, with MJ threads, classifications: 450 MPa (at ambient temperature)/120 °C, 450 MPa (at ambient temperature)/235 °C, 600 MPa (at ambient temperature)/425 °C, 900 MPa (at ambient temperature)/235 °C, 900 MPa (at ambient temperature)/315 °C, 900 MPa (at ambient temperature)/650 °C, 1 100 MPa (at ambient temperature)/235 °C, 1 100 MPa (at ambient temperature)/730 °C and 1 250 MPa (at ambient temperature)/600 °C. Dimensions
immediate downloadReleased: 2016-03-31
BS ISO 9618:2016 Aerospace. Nuts, hexagonal, slotted (castellated), reduced height, normal across flats, with MJ threads, classifications: 450 MPa (at ambient temperature)/120 °C, 450 MPa (at ambient temperature)/235 °C, 600 MPa (at ambient temperature)/425 °C, 900 MPa (at ambient temperature)/235 °C, 900 MPa (at ambient temperature)/315 °C, 900 MPa (at ambient temperature)/650 °C, 1 100 MPa (at ambient temperature)/235 °C, 1 100 MPa (at ambient temperature)/730 °C and 1 250 MPa (at ambient temperature)/600 °C. Dimensions

BS ISO 9618:2016

Aerospace. Nuts, hexagonal, slotted (castellated), reduced height, normal across flats, with MJ threads, classifications: 450 MPa (at ambient temperature)/120 °C, 450 MPa (at ambient temperature)/235 °C, 600 MPa (at ambient temperature)/425 °C, 900 MPa (at ambient temperature)/235 °C, 900 MPa (at ambient temperature)/315 °C, 900 MPa (at ambient temperature)/650 °C, 1 100 MPa (at ambient temperature)/235 °C, 1 100 MPa (at ambient temperature)/730 °C and 1 250 MPa (at ambient temperature)/600 °C. Dimensions

Format
Availability
Price and currency
English Secure PDF
Immediate download
154.10 EUR
English Hardcopy
In stock
154.10 EUR
Standard number:BS ISO 9618:2016
Pages:14
Released:2016-03-31
ISBN:978 0 580 86450 6
Status:Standard
BS ISO 9618:2016 Aerospace Nuts

BS ISO 9618:2016 Aerospace Nuts

Introducing the BS ISO 9618:2016 Aerospace Nuts, a critical component designed to meet the rigorous demands of the aerospace industry. These hexagonal, slotted (castellated) nuts are engineered with precision to ensure optimal performance in high-stress environments. With reduced height and normal across flats, these nuts are equipped with MJ threads, making them an ideal choice for aerospace applications where reliability and durability are paramount.

Key Features

  • Hexagonal, Slotted (Castellated) Design: Provides secure fastening and easy installation, ensuring that the nuts remain firmly in place even under extreme conditions.
  • Reduced Height: Offers a compact solution without compromising on strength, making it suitable for applications with space constraints.
  • MJ Threads: Specifically designed for aerospace applications, these threads provide superior strength and resistance to vibration.

Performance Classifications

The BS ISO 9618:2016 Aerospace Nuts are classified based on their tensile strength and temperature resistance, ensuring they meet the specific needs of various aerospace applications:

  • 450 MPa (at ambient temperature)/120 °C
  • 450 MPa (at ambient temperature)/235 °C
  • 600 MPa (at ambient temperature)/425 °C
  • 900 MPa (at ambient temperature)/235 °C
  • 900 MPa (at ambient temperature)/315 °C
  • 900 MPa (at ambient temperature)/650 °C
  • 1 100 MPa (at ambient temperature)/235 °C
  • 1 100 MPa (at ambient temperature)/730 °C
  • 1 250 MPa (at ambient temperature)/600 °C

Technical Specifications

These aerospace nuts are manufactured in compliance with the BS ISO 9618:2016 standard, ensuring they meet the highest quality and safety standards. The standard was released on March 31, 2016, and the document spans 14 pages, providing comprehensive details on the dimensions and specifications of these nuts.

ISBN: 978 0 580 86450 6

Applications

The BS ISO 9618:2016 Aerospace Nuts are designed for use in a variety of aerospace applications, including:

  • Aircraft Manufacturing: Ensures secure fastening of components in aircraft structures, contributing to overall safety and performance.
  • Spacecraft Assembly: Provides reliable fastening solutions for spacecraft, where performance under extreme conditions is critical.
  • Defense and Military Equipment: Suitable for use in military vehicles and equipment, where durability and reliability are essential.

Why Choose BS ISO 9618:2016 Aerospace Nuts?

Choosing the right components for aerospace applications is crucial to ensure safety, reliability, and performance. The BS ISO 9618:2016 Aerospace Nuts offer several advantages:

  • Compliance with International Standards: Manufactured in accordance with the BS ISO 9618:2016 standard, these nuts meet global quality and safety requirements.
  • High-Performance Materials: Made from materials that provide excellent tensile strength and temperature resistance, ensuring long-lasting performance.
  • Versatile Applications: Suitable for a wide range of aerospace applications, from commercial aircraft to military equipment.

Conclusion

The BS ISO 9618:2016 Aerospace Nuts are an essential component for any aerospace application requiring high strength, reliability, and compliance with international standards. With their hexagonal, slotted design, reduced height, and MJ threads, these nuts provide a secure and durable fastening solution that meets the demanding requirements of the aerospace industry. Whether you are involved in aircraft manufacturing, spacecraft assembly, or defense equipment production, these nuts are the ideal choice for ensuring the safety and performance of your projects.

DESCRIPTION

BS ISO 9618:2016


This standard BS ISO 9618:2016 Aerospace. Nuts, hexagonal, slotted (castellated), reduced height, normal across flats, with MJ threads, classifications: 450 MPa (at ambient temperature)/120 °C, 450 MPa (at ambient temperature)/235 °C, 600 MPa (at ambient temperature)/425 °C, 900 MPa (at ambient temperature)/235 °C, 900 MPa (at ambient temperature)/315 °C, 900 MPa (at ambient temperature)/650 °C, 1 100 MPa (at ambient temperature)/235 °C, 1 100 MPa (at ambient temperature)/730 °C and 1 250 MPa (at ambient temperature)/600 °C. Dimensions is classified in these ICS categories:
  • 49.030.30 Nuts

This International Standard specifies the dimensions of hexagon slotted (castellated) nuts, reduced height, normal across flats, with MJ threads, of classifications: 450 MPa/120 °C, 450 MPa/235 °C, 600 MPa/425 °C, 900 MPa/235 °C, 900 MPa/315 °C, 900 MPa/650 °C, 1 100 MPa/235 °C, 1 100 MPa/730 °C, and 1 250 MPa/600 °C.

NOTE 1 450 MPa, 600 MPa, 900 MPa, 1 100 MPa and 1 250 MPa corresponds to the minimum tensile stress which the nut is able to withstand at ambient temperature without breaking or cracking when tested with a bolt of a higher strength class.

NOTE 2 120 °C, 235 °C, 425 °C, 315 °C, 650 °C, 730 °C and 600 °C corresponds to the maximum temperature that the nut is able to withstand without permanent alteration to its original characteristics, after ambient temperature has been restored. The maximum temperature is conditioned by the surface treatment.

These nuts are intended to be used with split pins in conformity with ISO 1234.

This International Standard is applicable for the compilation of aerospace product standards.
