BS ISO 9631:2018 Rubber Seals - Joint Rings for Pipelines

Introducing the BS ISO 9631:2018 standard, a comprehensive specification for rubber seals and joint rings designed specifically for pipelines used in hot-water supply systems up to 110 °C. This standard is essential for ensuring the quality, durability, and performance of rubber seals in high-temperature environments, making it a critical resource for engineers, manufacturers, and quality assurance professionals in the plumbing and heating industries.

Key Features and Benefits

The BS ISO 9631:2018 standard provides detailed specifications for the material composition and performance requirements of rubber seals used in hot-water pipelines. Here are some of the key features and benefits of this standard:

• Temperature Resistance: Designed to withstand temperatures up to 110 °C, ensuring reliable performance in hot-water supply systems.
• Material Specifications: Detailed guidelines on the material properties required for optimal seal performance, including elasticity, tensile strength, and resistance to thermal degradation.
• Quality Assurance: Provides a benchmark for quality control, helping manufacturers produce seals that meet international standards and customer expectations.
• Durability: Ensures long-lasting performance and reduces the risk of leaks and failures in pipeline systems.
• Compatibility: Suitable for a wide range of pipeline materials and configurations, offering versatility in application.

Technical Specifications

The BS ISO 9631:2018 standard is a 24-page document that provides in-depth technical specifications for rubber seals used in hot-water pipelines. Here are some of the technical details included in the standard:

• Standard Number: BS ISO 9631:2018
• Pages: 24
• Release Date: March 14, 2018
• ISBN: 978 0 580 85474 3
• Status: Standard

Applications and Use Cases

The BS ISO 9631:2018 standard is applicable to a wide range of industries and use cases, including:

• Residential and Commercial Plumbing: Ensures the reliability and safety of hot-water supply systems in homes, offices, and commercial buildings.
• Industrial Heating Systems: Provides guidelines for seals used in industrial applications where high-temperature water is used for heating processes.
• Municipal Water Supply: Supports the development of robust infrastructure for municipal hot-water distribution networks.
• HVAC Systems: Ensures the integrity of seals in heating, ventilation, and air conditioning systems that utilize hot water.

Why Choose BS ISO 9631:2018?

Choosing the BS ISO 9631:2018 standard for your rubber seal needs offers numerous advantages:

• International Recognition: As an ISO standard, it is recognized and respected worldwide, ensuring compliance with global best practices.
• Comprehensive Coverage: Covers all aspects of material specification, from chemical composition to physical properties, providing a complete guide for manufacturers and engineers.
• Enhanced Safety: By adhering to this standard, you can enhance the safety and reliability of your hot-water supply systems, protecting both property and people.
• Cost Efficiency: Reduces the risk of costly repairs and downtime by ensuring the use of high-quality, durable seals.

Conclusion

The BS ISO 9631:2018 standard is an indispensable resource for anyone involved in the design, manufacture, or maintenance of hot-water supply systems. By providing clear and detailed specifications for rubber seals, this standard helps ensure the safety, reliability, and efficiency of pipeline systems operating at high temperatures. Whether you are an engineer, a manufacturer, or a quality assurance professional, the BS ISO 9631:2018 standard is your key to achieving excellence in hot-water pipeline sealing solutions.

BS ISO 9631:2018

This standard BS ISO 9631:2018 Rubber seals. Joint rings for pipelines for hot-water supply up to 110 °C. Specification for the material is classified in these ICS categories:

• 83.140.50 Seals

This document specifies material requirements for vulcanized rubber seals for hot drinking and non-drinking water supply (up to 110 °C).

The different seal designations specified are defined according to seal type, seal application and the requirements for a particular seal (see Table 2).

General requirements for finished joint seals are also given. Any additional requirements called for by the particular application are specified in the relevant product standards, taking into account that the performance of pipe joints is a function of the seal material properties, seal geometry and pipe joint design. This document is intended to be used where appropriate, in conjunction with product standards which specify performance requirements for joints.

This document is applicable to joint seals for use with all pipeline materials, including metals, clay, fibre cement, concrete, reinforced concrete, plastics and glass-reinforced plastics.

It is applicable to elastomeric components of composite and non-composite seals. In the case of composite seals made from materials with hardness ranging from 76 IRHD to 95 IRHD, the requirements for elongation at break, compression set and stress relaxation apply only when the material participates in the sealing function or contributes to the long-term stability of the seal.

The material requirements specified in this document are designed for long term performances and a potential lifetime of 50 years. The lifetime of a sealing depends not only on material performance but also on other parameters which are not defined in this document like the mounting design, the quality of assembly and the combination with operating conditions. Joint rings made from cellular rubber materials are not covered by this document.
