immediate downloadReleased: 1989-09-29
BS M 61:1989
Specification for envelope dimensions of "P" clamps (loop clamps) for fluid systems
Format
Availability
Price and currency
English Secure PDF
Immediate download
151.20 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
15.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
45.36 EUR
English Hardcopy
In stock
151.20 EUR
| Standard number: | BS M 61:1989 |
| Pages: | 8 |
| Released: | 1989-09-29 |
| ISBN: | 0 580 17507 3 |
| Status: | Standard |
DESCRIPTION
BS M 61:1989
This standard BS M 61:1989 Specification for envelope dimensions of "P" clamps (loop clamps) for fluid systems is classified in these ICS categories:
- 49.080 Aerospace fluid systems and components
This International Standard specifies maximum and minimum dimensions for “P” clamps (loop clamps) installed by means of a bolt with a nominal diameter of 5 mm.
The specified dimensions define a dimensional envelope. This International Standard shall not be considered as an interchangeability standard. The tolerances for each type of clamp are to be defined in the parts standards drawings.
Maximum and minimum dimensions for 'P' clamps, fixed by means of a bolt with a nominal diameter of 5 mm, and intended for the support of rigid tubing or hoses.
