Homepage>IEC Standards>IEC 60169-22:1985 - Radio-frequency connectors. Part 22: R.F. two-pole bayonet coupled connectors for use with shielded balanced cables having twin inner conductors (Type BNO)
download between 0-24 hoursReleased: 1985-01-01
IEC 60169-22:1985 - Radio-frequency connectors. Part 22: R.F. two-pole bayonet coupled connectors for use with shielded balanced cables having twin inner conductors (Type BNO)

IEC 60169-22:1985

Radio-frequency connectors. Part 22: R.F. two-pole bayonet coupled connectors for use with shielded balanced cables having twin inner conductors (Type BNO)

Connecteurs pour fréquences radioélectriques. Vingt-deuxième partie: Connecteurs à deux pôles pour fréquences radioélectriques à verrouillage à baïonnette, applicables à des câbles symétriques blindés à deux conducteurs intérieurs (type BNO)

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
44.00 EUR
English/French - Bilingual Hardcopy
in stock
44.00 EUR
Standard number:IEC 60169-22:1985
Released:1985-01-01
Language:English/French - Bilingual
DESCRIPTION

IEC 60169-22:1985

Specifies r.f. unmatched 2-pole connectors for use with a variety of balanced shielded cables having twin inner conductors which normally have a characteristic impedance ranging from 75 ohm to 130 ohm. Provides mating face and panel fixing dimensions, ratings, information on climatic category, gauging and type approval tests. These connectors are for low power, quick connect/disconnect applications using a bayonet coupling mechanism and are commonly known as type BNO.
