Homepage>IEC Standards>IEC 60191-6-2:2001 - Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages
Sponsored link
download between 0-24 hoursReleased: 2001-12-11
IEC 60191-6-2:2001 - Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages

IEC 60191-6-2:2001

Mechanical standardization of semiconductor devices - Part 6-2: General rules for the preparation of outline drawings of surface mounted semiconductor devices packages - Design guide for 1,50 mm, 1,27 mm and 1,00 mm pitch ball and column terminal packages

Normalisation mécanique des dispositifs à semiconducteurs - Partie 6-2: Règles générales pour la préparation des dessins d'encombrement des dispositifs à semiconducteurs pour montage en surface - Guide de conception pour les boîtiers à broches en forme de billes et de colonnes, avec des pas de 1,50 mm, 1,27 mm et 1,00 mm

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
48.89 USD
English/French - Bilingual Hardcopy
in stock
48.89 USD
Standard number:IEC 60191-6-2:2001
Released:2001-12-11
Language:English/French - Bilingual
DESCRIPTION

IEC 60191-6-2:2001

IEC 60191-6-2:2001 covers the requirements for the preparation of drawings of integrated circuit outlines for the various ball terminal packages, e.g. ceramic ball grid array (C-BGA), plastic ball grid array (P-BGA), tape ball grid array (T-BGA) and others as well as column terminal packages, e.g. ceramic column grid array (C-CGA).
