Homepage>IEC Standards>IEC 60317-61:2020 - Specifications for particular types of winding wires - Part 61: Polyester glass-fibre wound, resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 180
Sponsored link
download between 0-24 hoursReleased: 2020-05-08
IEC 60317-61:2020 - Specifications for particular types of winding wires - Part 61: Polyester glass-fibre wound, resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 180

IEC 60317-61:2020

Specifications for particular types of winding wires - Part 61: Polyester glass-fibre wound, resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 180

Spécifications pour types particuliers de fils de bobinage - Partie 61: Fil de section rectangulaire en cuivre nu ou émaillé, guipé de fibres de verre polyester imprégnées de résine ou de vernis, d'indice de température 180

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
44.00 EUR
English/French - Bilingual Hardcopy
in stock
44.00 EUR
Standard number:IEC 60317-61:2020
Released:2020-05-08
Language:English/French - Bilingual
DESCRIPTION

IEC 60317-61:2020

IEC 60317-61:2020 specifies the requirements of polyester glass-fibre wound, resin or varnish impregnated bare, grade 1 or grade 2 enamelled rectangular copper winding wires, temperature index 180. The impregnating agent can be, for instance, epoxy, polyester, or polyesterimide resin based. NOTE For this type of wire, the heat shock test is inappropriate and therefore a heat shock temperature cannot be established. Consequently, a class based on the requirements for temperature index and heat shock temperature cannot be specified. The range of nominal conductor dimensions covered by this document is: - width: min. 2,0 mm max. 16,0 mm; - thickness: min. 0,80 mm max. 5,60 mm. The specified combinations of width and thickness as well as the specified width/thickness ratio are according to IEC 60317-0-8. This second edition cancels and replaces the first edition published in 2012. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: - revision of the title of the standard; - revision to Clause 1, Scope; - revision to the descriptions of grades of thickness of polyester glass-fibre coverings in 3.2.2.
