IEC 60512-99-003:2023
Connectors for electrical and electronic equipment - Tests and measurements - Part 99-003: Endurance test schedules - Test 99c: Test schedule for balanced single-pair connectors separating (unmating) under electrical load
Connecteurs pour équipements électriques et électroniques - Essais et mesures - Partie 99-003: Programmes d’essais d’endurance - Essai 99c: Programme d’essai des connecteurs à une seule paire symétrique lors de la séparation (désaccouplement) sous charge électrique
| Standard number: | IEC 60512-99-003:2023 |
| Released: | 2023-09-29 |
| Language: | English/French - Bilingual |
IEC 60512-99-003:2023
IEC 60512-99-003:2023 is used for the assessment of connectors within the scope of SC 48B that are used in balanced single-pair communication cabling with remote power, in support of e.g., IEEE 802.3 remote powering applications for point-to-point connections. The object of this document is to detail a test schedule to determine the ability of sets of single-pair connectors as defined in the IEC 63171 series to withstand a minimum of 100 mechanical operations with electrical load, where an electrical current is being passed through the connector in accordance with IEC 60512-9-3 during the separation (unmating) step. This document does not cover multidrop powering applications of single-pair connectors.
