download between 0-24 hoursReleased: 1987-01-01
IEC 60603-5:1987
Connectors for frequencies below 3 MHz for use with printed boards - Part 5: Edge-socket connectors and two-part connectors for double-sided printed boards with 2,54 mm (0,1 in) spacing
Connecteurs pour fréquences inférieures à 3 MHz pour utilisation avec cartes imprimées - Partie 5: Connecteurs encartables et connecteurs enfichables pour cartes imprimées double face au pas de 2,54 mm (0,1 in)
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
209.00 EUR
English/French - Bilingual Hardcopy
in stock
209.00 EUR
| Standard number: | IEC 60603-5:1987 |
| Released: | 1987-01-01 |
| Language: | English/French - Bilingual |
DESCRIPTION
IEC 60603-5:1987
Covers a range of connectors with 2.54 mm (0.1 in) spacing intended to connect a double-sided printed board to another printed board or wires. Two kinds of connector are available: -One-part edge-socket connector: Fixed connector or (female) receptacle is intended to mate with edge-board contacts. -Two-part connector: Fixed connector or (female) receptacle is intended to mate with free connector of board-mounted (male) connector. For these two cases, fixed connectors or (female) receptacles are the same.
