IEC 60796-2:1990

Microprocessor system bus - 8-bit and 16-bit data (MULTIBUS I) - Part 2: Mechanical and pin descriptions for the system BUS configuration, with edge connectors (direct)

Bus système à microprocesseurs - Données: 8 bits et 16 bits (MULTIBUS I) - Deuxième partie: Description mécanique et brochage pour la configuration du bus système, avec des connecteurs en bout de carte

English/French - Bilingual PDF

Immediate download

44.00 EUR

English/French - Bilingual Hardcopy

in stock

44.00 EUR

Standard number:	IEC 60796-2:1990
Released:	1990-10-15
Language:	English/French - Bilingual

DESCRIPTION

IEC 60796-2:1990

Applies to an interface used to connect microprocessor system components by means of the edge connector (direct) type backplane. Describes all the physical and mechanical specifications that a designer shall be concerned with when designing a backplane or when designing printed circuit boards that plug into the system bus interface. Note: -For the price of this publication, please consult the ISO/IEC price code list.
