IEC 61076-2-116:2022
Connectors for electrical and electronic equipment - Product requirements - Part 2 -116: Detail specification for circular connectors size 15 with up to 3+PE power contacts and auxiliary contacts, with bayonet-locking.
Connecteurs pour équipements électriques et électroniques - Exigences de produit - Partie 2-116: Spécification particulière pour les connecteurs circulaires de taille 15 avec jusqu’à 3+PE contacts de puissance et contacts auxiliaires, avec verrouillage à baïonnette
| Standard number: | IEC 61076-2-116:2022 |
| Released: | 2022-12-15 |
| Language: | English/French - Bilingual |
IEC 61076-2-116:2022
IEC 61076-2-116:2022 specifies circular connectors size 15 with bayonet-locking, with up to 3 power contacts with rated insulation voltage up to 630 V AC/DC and rated current up to 20 A, plus PE, and up to 3 auxiliary contacts with rated insulation voltage up to 63 V AC/DC and rated current up to 10 A, that are typically used for industrial power supply and power applications, such as the feeding and control of 3-phase asynchronous motors. These connectors consist of both fixed and free connectors either rewireable or non-rewireable, with bayonet-locking. Male connectors have round contacts, either power or signal, Ø1,6 mm.
