IEC 61169-15:2021
Radio-frequency connectors - Part 15: Sectional specification - RF coaxial connectors with inner diameter of outer conductor 4,13 mm (0,163 in) with threaded coupling - Characteristic impedance 50 Ω (type SMA)
Connecteurs pour fréquences radioélectriques - Partie 15: Spécification intermédiaire - Connecteurs coaxiaux pour fréquences radioélectriques avec diamètre intérieur du conducteur extérieur de 4,13 mm (0,163 in) à couplage fileté - Impédance caractéristique 50 Ω (type SMA)
| Standard number: | IEC 61169-15:2021 |
| Released: | 2021-01-19 |
| Language: | English/French - Bilingual |
IEC 61169-15:2021
IEC 61169-15:2021 provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with inner diameter of outer conductor 4,13 mm (0,163 in) with threaded coupling with a characteristic impedance of 50 Ω (type SMA). This document specifies mating face dimensions for high performance connectors – grade 1, dimensional details of standard test connectors – grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series SMA RF connectors. This document indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.
