Homepage>IEC Standards>IEC 61169-26:2013 - Radio-frequency connectors - Part 26: Sectional specification for TNCA series RF coaxial connectors
Sponsored link
download between 0-24 hoursReleased: 2013-01-29
IEC 61169-26:2013 - Radio-frequency connectors - Part 26: Sectional specification for TNCA series RF coaxial connectors

IEC 61169-26:2013

Radio-frequency connectors - Part 26: Sectional specification for TNCA series RF coaxial connectors

Connecteurs pour fréquences radioélectriques - Partie 26: Spécification intermédiaire pour les connecteurs coaxiaux RF série TNCA

Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
209.00 EUR
English/French - Bilingual Hardcopy
in stock
209.00 EUR
Standard number:IEC 61169-26:2013
Released:2013-01-29
Language:English/French - Bilingual
DESCRIPTION

IEC 61169-26:2013

IEC 61169-26:2013 is a sectional specification (SS), it provides information and rules for the preparation of detail specifications (DS) for TNCA series RF coaxial connectors, with characteristic impedance of 50 Ohms, with threaded coupling and operating frequency limit up to 18 GHz, used in wireless, communication, instrument, antenna, test and measurements, radar, and other fields, connecting with RF cables or micro-strips. It also prescribes mating face dimensions for general connectors-grade 2, dimensional details of standard test connectors-grade 0, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to TNCA series connectors.
