download between 0-24 hoursReleased: 2008-11-13
IEC 61169-38:2008
Radio-frequency connectors - Part 38: Sectional specification - Radio frequency coaxial connectors model, slide-in (rack and panel applications) - Characteristic impedance 50 Ω (type TMA) - 50 Ω applications
Connecteurs pour fréquences radioeléctriques - Partie 38: Spécification intermédiaire - Connecteurs coaxiaux pour fréquences radioélectriques, de type glissant (applications en panneau et fond de panier) - Impédance caractéristique 50 Ω (type TMA) - Applications à 50 Ω
Format
Availability
Price and currency
English/French - Bilingual PDF
Immediate download
220.00 EUR
English/French - Bilingual Hardcopy
in stock
220.00 EUR
| Standard number: | IEC 61169-38:2008 |
| Released: | 2008-11-13 |
| Language: | English/French - Bilingual |
DESCRIPTION
IEC 61169-38:2008
IEC 61169-38:2008 which is a sectional specification, provides information and rules for the preparation of detail specifications for series TMA r.f. connectors together with the pro forma blank detail specification. Series TMA connectors have a characteristic impedance of 50 Ω and are normally used with R.F cables or with microstrip in microwave fields that has a blind-entry and middle low-power. The connectors are usable up to a frequency of at least 6 GHz.
