IEC 61249-2-45:2018
Materials for printed boards and other interconnecting structures - Part 2-45: Reinforced base materials clad and unclad - Non-halogenated epoxide non-woven/woven E-glass reinforced laminate sheets of thermal conductivity 1,0 W/(m•K) and defined flammability (vertical burning test), copper-clad for lead-free assembly
Matériaux pour circuits imprimés et autres structures d'interconnexion - Partie 2-45: Matériaux de base renforcés, plaqués et non plaqués - Feuilles stratifiées renforcées en verre de type E tissé/non tissé époxyde non halogéné, de conductivité thermique 1,0 W/(m•K) et d'inflammabilité définie (essai de combustion verticale), plaquées cuivre pour les assemblages sans plomb
| Standard number: | IEC 61249-2-45:2018 |
| Released: | 2018-01-10 |
| Language: | English/French - Bilingual |
IEC 61249-2-45:2018
IEC 61249-2-45:2018 gives requirements for properties of non-halogenated epoxide non‑woven reinforced core/woven E-glass reinforced surface laminate sheets of thermal conductivity and defined flammability (vertical burning test), copper-clad for lead-free assembly in thicknesses of 0,60 mm up to 1,70 mm. The flammability rating is achieved through the use of non-halogenated fire retardants reacted as part of the epoxide polymeric structure. The glass transition temperature is defined to be 105 °C minimum. Thermal conductivity is defined to be (1,0 ± 0,15) W/(m•K).
