IEC 62153-4-7:2021
Metallic cables and other passive components test methods - Part 4-7: Electromagnetic compatibility (EMC) - Test method for measuring of transfer impedance ZT and screening attenuation aS or coupling attenuation aC of connectors and assemblies - Triaxial tube in tube method
Méthodes d’essai des câbles métalliques et autres composants passifs - Partie 4-7: Compatibilité électromagnétique (CEM) - Méthode d’essai pour mesurer l’impédance de transfert, ZT,et l’affaiblissement d’écrantage, aS,ou l’affaiblissement de couplage, aC, des connecteurs et des cordons - Méthode triaxiale en tubes concentriques
| Standard number: | IEC 62153-4-7:2021 |
| Released: | 2021-07-23 |
| Language: | English/French - Bilingual |
IEC 62153-4-7:2021
IEC 62153-4-7:2021 deals with the triaxial tube in tube method. This triaxial method is suitable to determine the surface transfer impedance and/or screening attenuation and coupling attenuation of mated screened connectors (including the connection between cable and connector) and cable assemblies. This method could also be extended to determine the transfer impedance, coupling or screening attenuation of balanced or multipin connectors and multicore cable assemblies. This third edition cancels and replaces the second edition published in 2015 and its Amendment 1:2018.This edition includes the following significant technical changes with respect to the previous edition: - Annex E contains informative information about the direct measurement of screening effectiveness of connectors; - Annex F gives normative information about mixed mode parameters; - Annex G contains normative information about accessories for measuring coupling attenuation; - Annex H discusses the low frequency screening attenuation.
