Homepage>IEC Standards>IEC 63068-2:2019 - Semiconductor devices - Non-destructive recognition criteria of defects in silicon carbide homoepitaxial wafer for power devices - Part 2: Test method for defects using optical inspection
download between 0-24 hoursReleased: 2019-01-30
IEC 63068-2:2019 - Semiconductor devices - Non-destructive recognition criteria of defects in silicon carbide homoepitaxial wafer for power devices - Part 2: Test method for defects using optical inspection

IEC 63068-2:2019

Semiconductor devices - Non-destructive recognition criteria of defects in silicon carbide homoepitaxial wafer for power devices - Part 2: Test method for defects using optical inspection

Format
Availability
Price and currency
English PDF
Immediate download
170.50 EUR
English Hardcopy
in stock
170.50 EUR
Standard number:IEC 63068-2:2019
Released:2019-01-30
Language:English
DESCRIPTION

IEC 63068-2:2019

IEC 63068-2:2019(E) provides definitions and guidance in use of optical inspection for detecting as-grown defects in commercially available 4H-SiC (Silicon Carbide) epitaxial wafers. Additionally, this document exemplifies optical images to enable the detection and categorization of the defects for SiC homoepitaxial wafers. This document deals with a non-destructive test method for the defects so that destructive methods such as preferential etching are out of scope in this document.
