ISO 10303-513:2000-Industrial automation systems and integration — Product data representation and exchange-Part 513: Application interpreted construct: Elementary boundary representation

ISO 10303-513:2000

ISO 10303-513:2000-Industrial automation systems and integration — Product data representation and exchange-Part 513: Application interpreted construct: Elementary boundary representation

Format
Availability
Price and currency
English PDF
Immediate download
230.00 EUR
English Hardcopy
In stock
230.00 EUR
Standard´s number:ISO 10303-513:2000
Pages:56
Edition:1
Released:2000
Language:English
DESCRIPTION

ISO 10303-513:2000


This part of ISO 10303 specifies the interpretation of the generic resources for the definition of an elementary boundary representation model. The following are within the scope of this part of ISO 10303: — the definition of an elementary_brep_shape_representation, this is a representation composed of one or more manifold_solid_breps each of which is defined with elementary geometry and complete explicit topology; — the definition of the unbounded geometry of curves and surfaces used in the definition of the faces of such a B-rep model; — the definition of the topological structure of a B-rep model; — 3D geometry; — B-reps; — elementary curves, these are lines or conics; — elementary_surfaces; — geometric transformations; — polylines; — unbounded geometry; — use of topology to bound geometric entities. The following are outside the scope of this part of ISO 10303: — 2D geometry; — bounded curves other than polylines; — bounded surfaces — offset curves and surfaces. This AIC is independent of any industrial application domain.
