ISO 22872:2024

This document defines common terms and symbols associated with geometrical product specifications (GPS) for use in the field of rolling bearings. This document gives requirements and recommendations on the transformation of GPS into figures and tables. This document includes the rules for the representation of symbols, tolerance values, limits of size, limit deviations and limit values for rolling bearings derived from GPS indications according to, for example, ISO 1101[7] and ISO 14405-1[13], including indications in textual documents and on technical drawings.
