ISO 530:1975-Aircraft — General purpose push-pull single-pole circuit-breakers — Dimensions

ISO 530:1975

ISO 530:1975-Aircraft — General purpose push-pull single-pole circuit-breakers — Dimensions

Format
Availability
Price and currency
English PDF
Immediate download
46.00 EUR
English Hardcopy
In stock
46.00 EUR
French PDF
Immediate download
46.00 EUR
French Hardcopy
In stock
46.00 EUR
Standard´s number:ISO 530:1975
Pages:2
Edition:1
Released:1975
DESCRIPTION

ISO 530:1975


The dimensions of ratings up to and including 35 A circuit breakers shall not exceed those shown in figure 1. The dimensions of the part projecting through the mounting panel shall be as shown in figure 1. The holes in the mounting panel for fixing the circuit-breaker shall be as shown in figure 2. The small panel hole may be used to prevent rotation of the circuit-breaker.
