ISO 9222-1:1989-Technical drawings — Seals for dynamic application-Part 1: General simplified representation

ISO 9222-1:1989

ISO 9222-1:1989-Technical drawings — Seals for dynamic application-Part 1: General simplified representation

Format
Availability
Price and currency
English PDF
Immediate download
46.00 EUR
English Hardcopy
In stock
46.00 EUR
French PDF
Immediate download
46.00 EUR
French Hardcopy
In stock
46.00 EUR
Standard´s number:ISO 9222-1:1989
Pages:2
Edition:1
Released:1989
DESCRIPTION

ISO 9222-1:1989


This method indicates only essential features ans should be used when it is not necessary to show the exact shape and details of the seals, for example in assembly drawings. The degree of simplification depends on the kind of object represented, the scale of the drawing and the purpose of documentation. ISO 9222-2 deals with the detailed simplified representation.
