ISO 9222-2:1989-Technical drawings — Seals for dynamic application-Part 2: Detailed simplified representation

ISO 9222-2:1989

ISO 9222-2:1989-Technical drawings — Seals for dynamic application-Part 2: Detailed simplified representation

Format
Availability
Price and currency
English PDF
Immediate download
115.00 EUR
English Hardcopy
In stock
115.00 EUR
French PDF
Immediate download
115.00 EUR
French Hardcopy
In stock
115.00 EUR
Standard´s number:ISO 9222-2:1989
Pages:12
Edition:1
Released:1989
DESCRIPTION

ISO 9222-2:1989


In contrast to the general simplified representation of part 1, this method shows more details of a seal, for example the configuration of lips. It should also be used when it is not necessary to show the exact shape and details of the seals, for example in assembly drawings. Elements and examples of this representation mode are given in tables and figures.
