ISO 9448-5:2013
ISO 9448-5:2013-Tools for pressing — Guide bushes-Part 5: Form D, ball cage bushes, headed, type 1
Format
Availability
Price and currency
English PDF
Immediate download
46.00 EUR
English Hardcopy
In stock
46.00 EUR
French PDF
Immediate download
46.00 EUR
French Hardcopy
In stock
46.00 EUR
| Standard´s number: | ISO 9448-5:2013 |
| Pages: | 4 |
| Edition: | 2 |
| Released: | 2013 |
DESCRIPTION
ISO 9448-5:2013
ISO 9448-5:2013 specifies the main dimensions and tolerances, in millimetres, of guide bushes of form D, headed ball cage bushes, type 1, intended for use in press tools and to be mounted in the clamp plate with transition fit and fixed to the plate by means of screws. It gives guidance on the materials, and specifies the hardness and the designation of bushes in accordance with ISO 9448-5:2013.
