ISO 9974-4:2016-Connections for general use and fluid power — Ports and stud ends with ISO 261 threads with elastomeric or metal-to-metal sealing-Part 4: Dimensions, design, test methods and requirements for external hex and internal hex port plugs

ISO 9974-4:2016

ISO 9974-4:2016-Connections for general use and fluid power — Ports and stud ends with ISO 261 threads with elastomeric or metal-to-metal sealing-Part 4: Dimensions, design, test methods and requirements for external hex and internal hex port plugs

Format
Availability
Price and currency
English PDF
Immediate download
70.00 EUR
English Hardcopy
In stock
70.00 EUR
French PDF
Immediate download
70.00 EUR
French Hardcopy
In stock
70.00 EUR
Standard´s number:ISO 9974-4:2016
Pages:10
Edition:2
Released:2016
DESCRIPTION

ISO 9974-4:2016


ISO 9974-4:2016 specifies dimensions and performance requirements for metric external hex and internal hex port plugs for use with ISO 9974‑1 ports. Port plugs in accordance with this document can be used at working pressures up to 63 MPa [630 bar[1]]. The permissible working pressure depends upon the plug end size, materials, design, working conditions, application, etc. Conformance to the dimensional information in this document does not guarantee rated performance. NOTE The Introduction of this document gives recommendations for ports and stud ends to be used for new designs in hydraulic fluid power applications. [1] 1 bar = 0,1 MPa = 105 Pa; 1 MPa = 1 N/mm2.
