PD 6490:1980 Guide to application of additional symbols (and index) for machine tools

PD 6490:1980

Guide to application of additional symbols (and index) for machine tools

Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
Standard number:PD 6490:1980
Pages:20
Released:1980-02-29
ISBN:0 580 11174 1
Status:Standard
DESCRIPTION

PD 6490:1980


This standard PD 6490:1980 Guide to application of additional symbols (and index) for machine tools is classified in these ICS categories:
  • 25.080.01 Machine tools in general
  • 01.080.20 Graphical symbols for use on specific equipment

This Published Document contains additions to the range of symbols given in BS 3641-1, BS 3641-2 and BS 3641-3, which are intended for use on an interim basis until the complete revision of BS 3641 can be carried out. This document also contains an index which relates to BS 3641-1, BS 3641-2 and BS 3641-3, and this Published Document.


Specifies additional machine tool symbols to those in BS 3641-3:1973. Contains index which also relates to BS 3641:Parts 1, 2 and 3.
