PD CEN/TR 13931:2009

This standard PD CEN/TR 13931:2009 Rotodynamic pumps. Forces and moments on flanges. Centrifugal, mixed flow and axial flow horizontal and vertical shafts pumps is classified in these ICS categories:

• 23.080 Pumps

This CEN Technical Report provides information for the calculation of maximum permissible forces and moments allowed on the flanges of various types of horizontal and vertical shaft rotodynamic pumps, caused by the reaction to pipework that is rigidly connected to the installation. This document does not take into account the effect of any elastic or deformable linkages, such as bellows, elastic joints, self butting sliding joints, etc.

This CEN Technical Report is not applicable to multistage monobloc pumps, whose outlets are remote from the installation plane, or to horizontal shaft pumps mounted vertically for installation reasons, such as, fixing to a vertical wall.
