PD ISO/TS 13399-50:2013

This standard PD ISO/TS 13399-50:2013 Cutting tool data representation and exchange is classified in these ICS categories:

• 35.240.50 IT applications in industry
• 25.100.01 Cutting tools in general

This part of ISO 13399 specifies a reference dictionary for reference systems for cutting tools, together with their descriptive properties and domains of values.

This part of ISO 13399 specifies a reference dictionary containing:

• definitions and identifications of the classes of reference systems for cutting tools, with an associated classification scheme;

• definitions and identifications of the data element types that represent the properties of reference systems for cutting tools;

• definitions and identifications of domains of values for describing the above-mentioned data element types.

Each class, property or domain of values of this application domain constitutes an entry of the reference dictionary defined in this part of ISO 13399. It is associated with a computer-sensible and human-readable definition, and with a computer-sensible identification. Identification of a dictionary entry allows unambiguous reference to it from any application that implements the information model defined in ISO 13399-1.

Definitions and identifications of dictionary entries are defined by means of standard data that consist of instances of the EXPRESS entity data types defined in the common dictionary schema, resulting from a joint effort between ISO/TC 184/SC 4 and IEC SC3D, and in its extensions defined in ISO 13584-24 and ISO 13584-25.

The following are within the scope of this part of ISO 13399:

• standard data that represent the various classes of connection systems for cutting tools;

• standard data that represent the various properties of connection systems for cutting tools;

• standard data that represent domains of values used for properties of connection systems for cutting tools;

• standard data that represent the various classes of reference systems for cutting tools;

• standard data that represent the various properties of reference systems for cutting tools;

• standard data that represent domains of values used for properties of reference systems for cutting tools;

• one implementation method by which the standard data defined in this part of ISO 13399 can be exchanged.

NOTE 1 The implementation method by which the standard data defined in this part of ISO 13399 can be exchanged is specified in ISO 10303-21.

The following are outside the scope of this part of ISO 13399:

• applications where these standard data might be stored or referenced;

• implementation methods other than the one defined in this part of ISO 13399 by which the standard data might be exchanged and referenced;

• information model for cutting tools;

• definitions of classes and properties for cutting items;

• definitions of classes and properties for tool items;

• definitions of classes and properties for assembly items.

• definitions of classes and properties for connection systems for cutting tools.

NOTE 2 The information model for cutting tools is defined in ISO 13399-1.

NOTE 3 The definitions of classes and properties for cutting items, tool items, adaptive items, assembly items and connection systems are provided in ISO/TS 13399-2, ISO/TS 13399-3, ISO/TS 13399-4, ISO/TS 13399-5 and ISO/TS 13399-60, respectively.
